ASRock H610M-HDV Micro-ATX Gaming Motherboard
|
Detail Info
- Supports 12th Gen Intel Core Processors (LGA1700)
- 5 Phase Power Design
- Supports DDR4 3200MHz
- 1 PCIe 4.0 x16, 1 PCIe 3.0 x1
- Graphics Output Options: HDMI, DisplayPort, D-Sub
- Realtek ALC887/897 7.1 CH HD Audio Codec
- 4 SATA3
- 4 USB 3.2 Gen1 (2 Rear, 2 Front)
- 6 USB 2.0 (4 Rear, 2 Front)
- Realtek Gigabit LAN
- Product Type : Motherboard
- Motherboard : H610
Product Details
HDMI 4k @60Hz
Supports the most recent HDMI 4K 60Hz graphics output specification. With the larger bandwidth and increased frame rate, the motion on your screen becomes more fluid and less blurry.
Premium Power Choke
Compared to traditional chokes, ASRock’s premium power chokes effectively make the saturation current up to three times better, thus providing enhanced and improved Vcore voltage to the motherboard.
Sapphire Black PCB
Pure black PCB appearance. The new Sapphire Black PCB represents rock-solid quality and gives the motherboard a more mysterious touch.
High Density Glass Fabric PCB
High Density Glass Fabric PCB design that reduces the gaps between the PCB layers to protect the motherboard against electrical shorts caused by humidity.
Full Spike Protection
Some sensitive digital components on the motherboard are vulnerable to power surges, the excessive current may cause your system to malfunction immediately. ASRock Full Spike Protection includes various technologies to prevent your motherboard’s components from being damaged by these unexpected voltage spikes.
Specifications
Unique Feature |
ASRock Super Alloy |
---|---|
|
- Premium Power Choke |
|
- Sapphire Black PCB |
|
- High Density Glass Fabric PCB |
|
ASRock Full Spike Protection (for all USB, Audio, LAN Ports) |
|
ASRock Live Update & APP Shop |
CPU |
- Supports 12th Gen Intel® Core™ Processors (LGA1700) |
|
- 5 Power Phase design |
|
- Supports Intel® Hybrid Technology |
|
- Supports Intel® Turbo Boost Max 3.0 Technology |
Chipset |
- Intel® H610 |
Memory |
- Dual Channel DDR4 Memory Technology |
|
- 2 x DDR4 DIMM Slots |
|
- Supports DDR4 non-ECC, un-buffered memory up to 3200 |
|
- Supports ECC UDIMM memory modules (operate in non-ECC mode) |
|
- Max. capacity of system memory: 64GB |
|
- Supports Intel® Extreme Memory Profile (XMP) 2.0 |
BIOS |
- 128Mb AMI UEFI Legal BIOS with multilingual GUI support |
|
- ACPI 6.0 Compliant wake up events |
|
- SMBIOS 2.7 Support |
|
- CPU Core/Cache, CPU Core/Cache Load-Line, CPU GT, CPU GT Load-Line, DRAM, +0.82V PCH, +1.05V PCH, VCCIN AUX, +1.8V PROC, +1.05V PROC Voltage Multi-adjustment |
Graphics |
- Intel® Xe Graphics Architecture (Gen 12) |
|
- Three graphics output options: D-Sub, HDMI and DisplayPort 1.4 |
|
- Supports HDMI 2.1 TMDS Compatible with max. resolution up to 4K x 2K (4096x2160) @ 60Hz |
|
- Supports DisplayPort 1.4 with DSC (compressed) max. resolution up to 8K (7680x4320) @ 60Hz / 5K (5120x3200) @ 120Hz |
|
- Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz |
|
- Supports HDCP 2.3 with HDMI 2.1 TMDS Compatible and DisplayPort 1.4 Ports |
|
*Intel® UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated. |
Audio |
- 7.1 CH HD Audio (Realtek ALC897/887 Audio Codec) |
|
- Supports Surge Protection |
LAN |
- PCIE x1 Gigabit LAN 10/100/1000 Mb/s |
|
- 1 x Realtek RTL8111H |
|
- Supports Wake-On-LAN |
|
- Supports Lightning/ESD Protection |
|
- Supports Energy Efficient Ethernet 802.3az |
|
- Supports PXE |
Slots |
|
CPU: |
- 1 x PCIe 4.0 x16 Slot (PCIE2), supports x16 mode* |
Chipset: |
- 1 x PCIe 3.0 x1 Slot (PCIE1)* |
|
*Supports NVMe SSD as boot disks |
Storage |
- 4 x SATA3 6.0 Gb/s Connectors |
Connector |
- 1 x SPI TPM Header |
|
- 1 x Chassis Intrusion and Speaker Header |
|
- 1 x CPU Fan Connector (4-pin)* |
|
- 1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)** |
|
- 1 x 24 pin ATX Power Connector |
|
- 1 x 8 pin 12V Power Connector |
|
- 1 x Front Panel Audio Connector |
|
- 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection) |
|
- 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection) |
|
*The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. |
|
*The Chassis/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power. |
|
CHA_FAN1/WP can auto detect if 3-pin or 4-pin fan is in use. |
Rear Panel I/O |
- 1 x PS/2 Mouse/Keyboard Port |
|
- 1 x D-Sub Port |
|
- 1 x HDMI Port |
|
- 1 x DisplayPort 1.4 |
|
- 2 x USB 3.2 Gen1 Ports (Supports ESD Protection) |
|
- 4 x USB 2.0 Ports (Supports ESD Protection) |
|
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) |
|
- HD Audio Jacks: Line in / Front Speaker / Microphone |
Software and UEFI |
|
Software |
- ASRock Motherboard Utility (A-Tuning) |
|
- ASRock XFast LAN |
UEFI |
- ASRock EZ Mode |
|
- ASRock Full HD UEFI |
|
- ASRock My Favorites in UEFI |
|
- ASRock Instant Flash |
|
- ASRock Internet Flash |
|
*These utilities can be downloaded from ASRock Live Update & APP Shop. |
Support CD |
- Drivers, Utilities, AntiVirus Software (Trial Version) |
Accessories |
- Quick Installation Guide, Support CD, I/O Shield |
|
- 2 x SATA Data Cables |
Hardware Monitor |
- Fan Tachometer: CPU, Chassis/Water Pump Fans |
|
- Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis/Water Pump Fans |
|
- Fan Multi-Speed Control: CPU, Chassis/Water Pump Fans |
|
- CASE OPEN detection |
|
- Voltage monitoring: CPU Vcore, DRAM, +0.82V PCH, +1.05V PCH, VCCIN AUX, VCCSA, +1.05V PROC, +12V, +5V, +3.3V |
Form Factor |
- Micro ATX Form Factor: 7.76-in x 7.4-in, 19.7 cm x 18.8 cm |
|
- Solid Capacitor design |
OS |
- Microsoft® Windows® 10 64-bit / 11 64-bit |
Certifications |
- FCC, CE |
|
- ErP/EuP ready (ErP/EuP ready power supply is required) |
